Mixing Kettle
Product Details
Introduction
TRANSOCEAN® mixing kettle is suitable for mixing several kinds of liquids or solids. Usually, one or two layers of impeller blades are included in the mixer. The blades force the fluids to move axially and circulate along the shaft. Mixing and precipitation prevention can be achieved in this process. Baffles can be mounted on the interior of the vessel to mitigate the influence of horizontal flow on the mixing effect. A cooling jacket is available as an option for temperature control in the case of thermosensitive products being processed.
Applications
●TRANSOCEAN® mixing kettle is widely used as a mixer for color mixing or precipitation prevention in industries such as paint, ink, adhesive, wastewater treatment, and like.
Features
● High mixing efficiency for liquid-liquid / liquid-solid materials
● Material of wetted parts: S.S.304/S.S.420/Chrome plated #45 steel
● Mounting mode: on platform
Technical specifications
|
Model |
TC-0.5 |
TC-1 |
TC-2 |
TC-3 |
TC-4 |
TC-5 |
TC-6 |
TC-8 |
TC-10 |
|
|
Motor power (KW) |
1.1 |
2.2 |
4 |
5 |
7.5 |
11 |
11 |
15 |
18.5 |
|
|
Tank volume (m3) |
0.5 |
1 |
2 |
3 |
4 |
5 |
6 |
8 |
10 |
|
|
Mixing speed (r.p.m.) |
130 |
130 |
88 |
88 |
88 |
88 |
88 |
88 |
63 |
|
|
Agitator dia.(mm) |
500 |
500 |
700 |
800 |
800 |
1200 |
1300 |
1250 |
1250 |
|
|
Agitator quantity |
1 |
1 |
2 |
2 |
2 |
2 |
2 |
3 |
3 |
|
|
External dimension(mm) |
D |
800 |
1000 |
1400 |
1600 |
1600 |
1800 |
1900 |
2000 |
2200 |
|
H |
1060 |
1355 |
1575 |
1725 |
2025 |
2125 |
2300 |
2725 |
3050 |
|
|
H1 |
550 |
550 |
1210 |
1240 |
1290 |
1510 |
1510 |
1660 |
1800 |
|
Remark
● Technical data listed are for reference only, which shall be customized according to the properties of the materials to be processed.
● High capacity not listed can be customized.
Why choose us?
●We are one of the leading manufacturers and suppliers of mixers, grinding equipment, filters, and filling machines in Wuxi city, Jiangsu province, China.
●Our quality control is implemented through the production process.
●We always keep customers informed of the updates on the preparation of the cargo at key points in time.
●We would like to provide a personalized design for each specific request for our customers.
● Flexible minimum order quantity is acceptable.
●We would provide door-to-door or door-to-port service upon customers' request.
●Contact us on WhatsApp or WeChat right away for perfectly cost-effective solutions.
FAQ
●Q: What is your minimum order quantity? Can you send me samples?
A: Our Min. OQ is 1 set. As our products are machines, it's hard to provide samples. Instead, we would provide our catalog, and you are also to visit our factories.
●Q: How can you solve the problems with the use of your products encountered by your overseas customers promptly?
A: We will respond within 24 hours after receiving the request from our customers. Initially, we will discuss the issue with our customers online to diagnose the problem. If it is caused by improper operation, we will guide our customers to operate the machine properly; if it results from a quality defect on the working part or wearing of our machine, we will deliver the spare parts by air/express ASAP for replacement and instruct our customers how to replace the defective part online. If necessary, we will share a short video to demonstrate the replacement. A one-year warranty from the shipment date is provided for our machines.
●Q: How is your price level?
A: At an average level in China. We don't provide cheap goods, for that is not our aim.
Hot Tags: mixing kettle, China mixing kettle manufacturers, suppliers, factory, Fluid Mixer, , Double Shaft Ribbon Mixer, , Kneader Mixer, Powder Granule Mixer
