Semi-Automatic Two Component Cartridge Closing Machine
Product Details
☆ Introduction:
● TRANSOCEAN® Semi-Automatic Two Component Cartridge Closing Machine are applicable for the plastic/aluminum laminate cartridge closing post to filling of various pastes, greases, sealants, etc. in the chemical, pharmaceutical, and food industries.
☆ Features:
● The cartridges loaded onto the cartridge closing station by an operator are automatically closed.
● The exhaust device is available for removing the air from the cartridge during closing.
☆ Technical Specifications:
|
Item |
Specifications |
|
Model |
SC-C1 |
|
Power Supply |
AC 1P/220V/50Hz (Customizable) |
|
Air Supply (bar) |
5 ~ 8 |
|
Air Consumption (m³/min) |
Max. 0.3 |
|
Productivity (PCS/min.) |
15~25 |
|
Applicable Tube Diameters (mm) |
Ø20~Ø50 |
|
Dimensions (L×W×H, mm) |
800*800*1400 |
|
N.W. (KGS) |
250 |
☆ Remark:
● Cap A and cap B can share the same capping machine in terms of 1:1.
● Cap A or cap B should be processed with the special capping unit irrespectively in terms of other ratios.
● The coding unit is available as an option.
